6Ton LX Type Single Beam Overhead Suspension Crane Electric With Remote Control

Product Categories
Henan Mine Crane Co.,Ltd.
Contact Now

6Ton LX Type Single Beam Overhead Suspension Crane Electric With Remote Control

Brand Name : KUANGYUAN

Model Number : LX

Certification : CE ISO GOST

Place of Origin : Henan,China

MOQ : 1Set

Price : USD 3580-7400

Payment Terms : L/C, T/T

Supply Ability : 40000 Sets per Year

Delivery Time : 30~40 work days

Packaging Details : Electrical and other parts packed by high quality plywood crate,Beams packed by plastic woven cloth.

Name : LX type electric single beam suspension crane

brand : KUANGYUAN

span : 3m~16m

lifting weight : 0.5T, 1T, 2T, 3T, 5T, 10T

lifting height : 6m, 9m, 12m, 18m

lifting speed : 8/0.8m/min

traveling speed : 20m/min, 30m/min

working class : A3~A5

motor : ZDY

electric current : 380V 50Hz 3ph

Contact Now

PRODUCT DESCRIPTION
Product introduction:

0.5T~10T Electric single beam remote control suspension type crane is widely used in plants warehouses, steel industries machine shops, material stocks to lift goods where the height from the rail surface to the lower edge of the truss is equal to or shorter than 500mm.

LX model suspension single girder overhead crane consists of main beam,end beam,electric hoist,electric control system,it is a light duty lifting equipment,economic and practical using,easy operation and using.
It is prohibited to use the equipment in the combustible, explosive or corrosives environment (Click here to learn more about suspension overhead crane).
It has two operational methods, ground or operational room which has open model and closed model and can be installed on left or right side according to the practical situation. And the direction of entering the gate has two forms, side way and ends in order to satisfy the users' choice users' different conditions.
LX single girder overhead crane is designed to cover a wide range of modern industrial demands, providing excellent value for money with no compromise on performance.
FEATURES AT A GLANCE
1. The structure: Electric hoist, single girder, end girders, electric control system;
Low height, small size, light weight, small pressing wheels;
2. The operation mode: cable operation, wireless remote control;
3. Advanced design concept the crane with outstanding distribution and performance, also at the maximum level of narrowing the lifting hook the operating limit of interval, effectively improves the space utilization, also make the customer may reduce the plant investment costs.
4. High performance braking system with anti-dust device can be automatically adjusted, safe service life more than 1000000 times.
6Ton LX Type Single Beam Overhead Suspension Crane Electric With Remote Control
6Ton LX Type Single Beam Overhead Suspension Crane Electric With Remote Control
6Ton LX Type Single Beam Overhead Suspension Crane Electric With Remote Control
6Ton LX Type Single Beam Overhead Suspension Crane Electric With Remote Control
6Ton LX Type Single Beam Overhead Suspension Crane Electric With Remote Control
PRODUCT SPECIFICATION
Safety device:
1. Weight overload protection device.
2. Top quality long time bearing polyurethane materials buffer.
3. Lifting limit switch and traveling limit switch.
4. Emergency stop system.
5. Zero voltage protection.
6. Phases protection device and so on.
6Ton LX Type Single Beam Overhead Suspension Crane Electric With Remote Control
Capacity
0.5~10ton
Span
3m~16m
Speed
Single speed , double speed
Usage
Normal workshop, warehouse
control
Pendant control, remote control
Lifting tool
Electric hoist

COMPANY PROFILE

>>>Interested? Click to read more about factory<<<
The 4200-plus-member factory covers over 142,0000 square meters and has a total asset of 660 million CNY. The 3,500-plus equipment enable the company to independently conduct over 20 technological flows, including lathing, milling, planning and grinding. The 180-plus intermediate and senor technical staff are responsible for R&D and production of all the products. The products have passed CE SGS TUV BV and CU-TR verification, and factory passed ISO9001-2008 international certification, IS014001:1996 environmental and ISO28001-2001 quality, health and safety certification. Our company has perfect quality-control system, strict and comprehensive management system, strong production capability and advanced test measures, guaranteeing high quality, output, competitiveness and market share.
COSTOMER CASE
6Ton LX Type Single Beam Overhead Suspension Crane Electric With Remote Control
FAQ
Are you interested in this LDA series single girder overhead crane?We are ready to quote for you according to your customizable paremeters as follows.
(kindly please provide the following information when sending enquiry to us.)
1. Lifting capacity :_____ton
2. Span :______meters (it is center to center distance between railways)
3. Lifting height :_____meters (it is the distance from center of hook to floor)
4. Travelling length:_____meters
5. Industrial voltage _____V, _____HZ, 3Phases
6. Control mode: Pendent or Remote control or cabin control?
7. Do you also need us to supply rail and bus bar: YES or NO?
8. What material to be lifted?
Welcome your requirements.
